Product Description
🔍
Product Overview
|
Field |
Details |
|---|---|
|
Manufacturer |
Honeywell |
|
Model/Part Number |
FS-FANWR-24R |
|
Description |
Cooling fan assembly for industrial control systems |
|
Approval Standards |
CE, UL, FM |
⚙️
Technical Specifications
|
Parameter |
Specification |
|---|---|
|
Fan Make / Model |
Papst 4184N/17X (Ball Bearing) |
|
Finger Guard Model |
Papst LZ30 |
|
Power Supply |
24 V DC, 9.5 W |
|
Voltage Range |
12–29 V DC (No reverse polarity protection) |
|
Air Flow |
360 m³/hr (211.8 CFM) |
|
Noise Level |
52 dB |
|
Fan Speed (Nominal) |
3200 RPM |
|
Minimum Speed (Readback Contact Close) |
1500 ± 100 RPM |
|
Lifecycle (MTBF) |
85,000 hrs @ 40°C (104°F) / 37,500 hrs @ 75°C (167°F) |
|
Ingress Protection |
IP20 |
🔌
Electrical – Readback Contact
|
Parameter |
Specification |
|---|---|
|
Max Switched Voltage |
300 V DC / 240 V AC |
|
Max Switched Current |
0.5 A |
|
Max Switched Power |
10 W |
🌡️
Environmental Limits
|
Parameter |
Range |
|---|---|
|
Operating Temperature |
-30°C to +75°C (-22°F to 167°F) |
🔩
Mechanical
|
Parameter |
Specification |
|---|---|
|
Dimensions (L × W × D) |
391 × 142 × 51 mm (15.4 × 5.59 × 2.01 in) |
|
Weight |
1.7 kg |
|
Connector Wire Strip |
7 mm |
|
Tightening Torque |
0.4–0.5 Nm |
|
Screwdriver Type |
SD 0.6 × 3.5 – DIN 5264 |
