Honeywell FS-BKM-0001 Control Processor Module
Honeywell FS-BKM-0001 Control Processor Module
Manufacturer: Honeywell
Product No.: FS-BKM-0001
Condition:1000 in stock
Product Type: Control Processor Module
Product Origin: USA
Payment: T/T, Western Union
Weight: 660g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
General Information
|
Manufacturer |
Honeywell |
|---|---|
|
Model/Part Number |
FS-BKM-0001 / FC-BKM-0001 |
|
Description |
Control Processor Module |
Technical Specifications
|
Specification |
Details |
|---|---|
|
Operating Temperature |
-5°C to +70°C (+23°F to +158°F) |
|
Storage Temperature |
-40°C to +85°C (-40°F to +185°F) |
|
Relative Humidity |
10-95% (non-condensing) |
|
Approvals |
CE, TUV, UL, CSA, FM |
|
Power Supply Voltage (24V) |
24 V DC _15% to +30% |
|
Power Supply Current (24V) |
Max. 20 mA (each 24V DC), Typical 7 mA (shared load) |
|
Power Supply Voltage (5V) |
5 V DC ± 10% |
|
Power Supply Current (5V) |
Max. 10 mA |
|
+24V_red Output Supply Voltage |
14-31 V DC |
|
Output Resistance |
Approx. 2 _ 1.1 kΩ (parallel) |
|
Short Circuit Protection |
Continuous |
|
Battery Make |
SAFT |
|
Battery Type |
LS14500CFG |
|
Battery Material |
Lithium Thionyl Chloride |
|
Battery Voltage |
Nominal 3.6 V |
|
Battery Capacity |
> 2 Ah |
|
Battery Size |
AA |
|
Battery Operating Temperature |
-40°C to +85°C (-40°F to +185°F) |
|
Physical Dimensions |
176 x 35.2 x 224 mm (H x W x D) / 6.93 x 1.4 x 8.81 in (H x W x D) |
|
Weight |
660 g |
