Product Description
General Information
|
Manufacturer |
Honeywell |
|---|---|
|
Model/Part Number |
FC-SDO-0824 |
|
Description |
Output Module |
|
Approvals |
CE, TUV, UL, CSA, FM |
Technical Specifications
|
Parameter |
Specification |
|---|---|
|
General Type Numbers |
FS-SDO-0824, FC-SDO-0824 |
|
Space Requirements |
4 TE, 3 HE (= 4 HP, 3U) |
|
Power Requirements |
5 V DC, 25 mA 24 V DC internal, 25 mA 24 V DC external, 70 mA (without output load) |
|
Number of Output Channels |
8 |
|
Output Specification |
24 V DC solid-state source, short-circuit proof |
|
Maximum Current |
550 mA |
|
Maximum Lamp Load |
120 mA (2.9 W) |
|
Maximum Load Capacitance |
1 µF |
|
Voltage Drop |
< 2.0 V DC at 500 mA |
|
Off Current |
< 0.1 mA |
|
WDG Input Current |
8 mA |
|
Module Code |
Holes A9, C9 |
|
Chassis Code |
Large pins A9, C9 |
