Product Description
🔍
Product Overview
|
Category |
Details |
|---|---|
|
Manufacturer |
Honeywell |
|
Model/Part Number |
FC-DO-1624 |
|
Type Numbers |
FS-DO-1624 / FC-DO-1624 |
|
Description |
24 V DC Digital Output Module, solid-state source type, 16-channel |
|
Application |
Suitable for safety and automation systems, designed for reliable digital output |
⚙️
Technical Specifications
|
Parameter |
Specification |
|---|---|
|
Approvals |
CE, TUV, UL, CSA |
|
Module Type |
Digital Output, Source Type |
|
Number of Output Channels |
16 |
|
Output Specification |
24 V DC solid-state, short-circuit proof |
|
Max Current per Channel |
100 mA |
|
Max Lamp Load |
50 mA (1.2 W) |
|
Max Load Capacitance |
1 µF |
|
Voltage Drop (at 100 mA) |
< 1.2 V DC |
|
Off-State Leakage Current |
< 0.1 mA |
|
Watchdog Input Current |
4 mA |
🔌
Power Requirements
|
Voltage |
Current Requirement |
|---|---|
|
5 V DC |
35 mA |
|
24 V DC |
85 mA (excluding output load) |
📐
Physical Specifications
|
Attribute |
Value |
|---|---|
|
Space Requirement |
4 TE, 3 HE (4 HP, 3U) |
|
Key Coding |
Holes A9, C21 |
|
Chassis Coding |
Large pins A9, C21 |
