Honeywell FC-BKM-001 Control Processor Module
Honeywell FC-BKM-001 Control Processor Module
Manufacturer: Honeywell
Product No.: FC-BKM-001
Condition:1000 in stock
Product Type: Control Processor Module
Product Origin: USA
Payment: T/T, Western Union
Weight: 660g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
___
Product Details
|
Category |
Details |
|---|---|
|
Manufacturer |
Honeywell |
|
Model/Part Number |
FC-BKM-001 |
|
Description |
Control Processor Module _ Part of Honeywell__ Safety Systems |
|
Type Numbers |
FS-BKM-0001 / FC-BKM-0001 |
|
Applications |
Suitable for safety and control systems in industrial automation |
_
_
___
Technical Specifications
|
Parameter |
Specification |
|---|---|
|
Operating Temperature |
-5°C to +70°C (+23°F to +158°F) |
|
Storage Temperature |
-40°C to +85°C (-40°F to +185°F) |
|
Relative Humidity |
10% to 95%, non-condensing |
|
Certifications |
CE, TUV, UL, CSA, FM |
_
_
__
Power Requirements
|
Parameter |
Specification |
|---|---|
|
24 V Supply Voltage |
24 V DC (range: -15% to +30%) |
|
24 V Supply Current |
Max. 20 mA (typ. 7 mA shared across system) |
|
5 VR Supply Voltage |
5 V DC ± 10% |
|
5 VR Supply Current |
Max. 10 mA |
|
+24V_red Output Voltage |
14_31 V DC |
|
Output Resistance |
Approx. 2 _ 1.1 kΩ (in parallel) |
|
Short Circuit Protection |
Yes, continuous |
_
_
__
Battery Information
|
Battery Attribute |
Details |
|---|---|
|
Manufacturer / Type |
SAFT / LS14500CFG |
|
Material |
Lithium Thionyl Chloride |
|
Voltage / Capacity |
3.6 V nominal / > 2 Ah |
|
Size |
AA |
|
Operating Temperature |
-40°C to +85°C (-40°F to +185°F) |
_
_
__
Physical Characteristics
|
Dimension |
Metric |
Imperial |
|---|---|---|
|
Height x Width x Depth |
176 mm x 35.2 mm x 224 mm |
6.93 in x 1.4 in x 8.81 in |
|
Weight |
660 g |
1.45 lbs |
_
