Honeywell DC-TCF902 51307945-176 REVA ControlEdge HC900 I/O Scanner Module

Honeywell DC-TCF902 51307945-176 REVA ControlEdge HC900 I/O Scanner Module

  • Manufacturer: Honeywell

  • Product No.: 51307945-176

  • Condition:1000 in stock

  • Product Type: ControlEdge HC900 I/O Scanner Module

  • Product Origin: USA

  • Payment: T/T, Western Union

  • Weight: 1000g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

Parameters

Product Overview

Parameter Details
Part Number DC-TCF902 51307945-176 REVA
Product Name ControlEdge HC900 I/O Scanner Module
Application I/O Scanner for ControlEdge HC900 Controller
Compatibility Interfaces with ControlEdge HC900 CPU and I/O modules
Function Collects input data and distributes output data for I/O modules in remote racks

Functional Specifications

Parameter Details
Module Type I/O Scanner (Scanner 1, Single Port)
Communication Single I/O port, IEEE 802.3 Ethernet 100Base-T physical layer
Data Exchange Synchronous with controller scan time for deterministic operation
Rack Address Configurable via DIP switches on module
Diagnostics Monitors I/O module status, reports to controller
Status Indicators Red/Green LED for mode or error, Green/Yellow LEDs for I/O port receive/transmit
Power Supply 5V DC from rack power supply (900P01-xxxx or 900P24-xxxx)
Power Consumption 5V: 770 mA max
Ambient Temperature Range 0 to 60°C
Mounting Standard 35mm DIN rail in I/O rack
Standards Compliance IEC 61850-3, IEC 61131-2, UL, CE



View full details

Product Description

Parameters

Product Overview

Parameter Details
Part Number DC-TCF902 51307945-176 REVA
Product Name ControlEdge HC900 I/O Scanner Module
Application I/O Scanner for ControlEdge HC900 Controller
Compatibility Interfaces with ControlEdge HC900 CPU and I/O modules
Function Collects input data and distributes output data for I/O modules in remote racks

Functional Specifications

Parameter Details
Module Type I/O Scanner (Scanner 1, Single Port)
Communication Single I/O port, IEEE 802.3 Ethernet 100Base-T physical layer
Data Exchange Synchronous with controller scan time for deterministic operation
Rack Address Configurable via DIP switches on module
Diagnostics Monitors I/O module status, reports to controller
Status Indicators Red/Green LED for mode or error, Green/Yellow LEDs for I/O port receive/transmit
Power Supply 5V DC from rack power supply (900P01-xxxx or 900P24-xxxx)
Power Consumption 5V: 770 mA max
Ambient Temperature Range 0 to 60°C
Mounting Standard 35mm DIN rail in I/O rack
Standards Compliance IEC 61850-3, IEC 61131-2, UL, CE
