Product Description
Product Overview
| Category | Details |
|---|---|
| Manufacturer | Honeywell |
| Model/Part Number | CC-TDOR01 51308376-175 |
| Description | Digital Output Relay Input/Output Termination Assembly (IOTA) designed for Honeywell Experion PKS Distributed Control Systems, providing 32-channel relay outputs for non-redundant applications |
| Key Features | 32 relay output channels, non-redundant, supports 24 VDC or 120/240 VAC loads, coated for harsh environments, integrates with Series C I/O modules, high reliability |
Technical Specifications
| Specification | Details |
|---|---|
| Model | CC-TDOR01 51308376-175 |
| Product Type | Digital Output Relay IOTA |
| Series | Experion PKS Series C |
| Number of Channels | 32 relay outputs |
| Output Voltage | 24 VDC or 120/240 VAC |
| Contact Rating | 3 A at 250 VAC or 3 A at 30 VDC |
| Power Supply | 24 VDC (via system backplane) |
| Operating Temperature | -40°C to 70°C (-40°F to 158°F) |
| Weight | Approx. 0.4-0.6 kg (0.88-1.32 lbs) |
External Connection Options
| Connection Type | Details |
|---|---|
| Supported Connections | Terminal blocks for field wiring, connects to Series C digital output modules via IOTA interface |
Functional Features
| Feature | Details |
|---|---|
| Relay Outputs | Controls high-power devices like motors, solenoids, and alarms |
| Environmental Protection | Conformal coating for resistance to harsh industrial conditions |
| Compatibility | Seamless integration with Experion PKS C300 controllers |
| Diagnostics | Supports status monitoring for operational reliability |
Model and Configuration
| Category | Details |
|---|---|
| Base Model | CC-TDOR01 |
| Configuration | Part number 51308376-175, non-redundant, coated |
