Product Description
🔍
Product Details
|
Category |
Details |
|---|---|
|
Manufacturer |
Honeywell |
|
Model/Part Number |
CC-TDOD51 |
|
Description |
Digital Output Module – 24V DC SINK Type (Open Drain), Non-Redundant |
|
System Compatibility |
Experion PKS Series C |
⚙️
Technical Specifications – Digital Output (SINK Type)
|
Parameter |
Specification |
|---|---|
|
Input/Output Model |
CC-PDOD51 – Digital Output, Field Isolated, Bussed, Coated |
|
IOTA Model Number |
CC-TDOD51 (Non-Redundant, 9”) |
|
Redundant IOTA Option |
CC-TDOD61 (Redundant, 12”) |
|
Output Channels |
32 |
|
Output Type |
SINK (Open Drain) |
|
Load Voltage Range |
15–30 V DC (Max) |
|
Load Current |
Max 0.1 A per channel |
|
Galvanic Isolation |
1000 VAC RMS (System to Field – user-supplied field power) |
|
On-State Voltage |
0 V DC (at 0.1 A max) |
|
Off-State Voltage |
24 V DC (typical) |
|
Off-State Leak Current |
Max 100 µA |
|
Turn-On/Turn-Off Time |
10 ms (maximum) |
|
Redundancy Switchover |
0 ms current gap (seamless switchover when redundancy is enabled) |
