| Output Channels |
32 channels, DC voltage (sourcing type) |
| Output Type |
Solid-state, sourcing |
| Voltage Range |
10 to 32 VDC |
| Current per Channel |
0.5 A max (sinking), 16 A max per module |
| Isolation |
Galvanically isolated, point to chassis |
| Failsafe |
User-specified state in case of communication loss |
| Diagnostics |
Green blinking LED for scanning status, red LED for module/channel diagnostics |
| Update Rate |
Synchronous with control execution |
| Power Supply |
5V DC (50 mA max), 24V DC (150 mA max) from rack power supply |
| Ambient Temperature Range |
0 to 60°C |
| Mounting |
Standard 35mm DIN rail in controller rack |
| Dimensions |
4.38" (111.1 mm) x 3.70" (94.0 mm) x 2.60" (66.0 mm) (L x W x H) |
| Standards Compliance |
IEC 61850-3, IEC 61131-2, UL, CE |
