Honeywell CC-PCNT05 Central Processing Unit

Honeywell CC-PCNT05 Central Processing Unit

  • Manufacturer: Honeywell

  • Product No.: CC-PCNT05

  • Condition:1000 in stock

  • Product Type: Central Processing Unit

  • Product Origin: USA

  • Payment: T/T, Western Union

  • Weight: 1000g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

CC-PCNT05 Parameters

Product Overview

Parameter Details
Part Number CC-PCNT05
Product Name ControlEdge HC900 C75 CPU Module
Application Central Processing Unit for ControlEdge HC900 Controller
Compatibility Interfaces with ControlEdge HC900 I/O modules via I/O Scanner
Function Executes control strategies, manages I/O communications, supports redundancy

Functional Specifications

Parameter Details
Processor High-performance CPU for loop and logic control
Memory 128MB battery-backed DDR2 RAM
I/O Capacity Up to 4608 Analog and Digital I/O points
Communication Dual Ethernet ports, two isolated RS-485 ports (Honeywell or Modbus RTU protocol)
Redundancy Supported with Redundant Switch Module (900RSM-xxxx) for Lead/Reserve CPU operation
Safety Rating SIL-2 certified for safety applications
Power Supply 5V DC and 24V DC from rack power supply (900P01-xxxx or 900P24-xxxx)
Power Consumption 5V: 500 mA max, 24V: 100 mA max
Ambient Temperature Range 0 to 60°C
Mounting Standard 35mm DIN rail in controller rack
Dimensions 4.38" (111.1 mm) x 3.70" (94.0 mm) x 2.60" (66.0 mm) (L x W x H)
Standards Compliance IEC 61850-3, IEC 61131-2, UL, CE, TUV, UL508, CSA



View full details

Product Description

CC-PCNT05 Parameters

Product Overview

Parameter Details
Part Number CC-PCNT05
Product Name ControlEdge HC900 C75 CPU Module
Application Central Processing Unit for ControlEdge HC900 Controller
Compatibility Interfaces with ControlEdge HC900 I/O modules via I/O Scanner
Function Executes control strategies, manages I/O communications, supports redundancy

Functional Specifications

Parameter Details
Processor High-performance CPU for loop and logic control
Memory 128MB battery-backed DDR2 RAM
I/O Capacity Up to 4608 Analog and Digital I/O points
Communication Dual Ethernet ports, two isolated RS-485 ports (Honeywell or Modbus RTU protocol)
Redundancy Supported with Redundant Switch Module (900RSM-xxxx) for Lead/Reserve CPU operation
Safety Rating SIL-2 certified for safety applications
Power Supply 5V DC and 24V DC from rack power supply (900P01-xxxx or 900P24-xxxx)
Power Consumption 5V: 500 mA max, 24V: 100 mA max
Ambient Temperature Range 0 to 60°C
Mounting Standard 35mm DIN rail in controller rack
Dimensions 4.38" (111.1 mm) x 3.70" (94.0 mm) x 2.60" (66.0 mm) (L x W x H)
Standards Compliance IEC 61850-3, IEC 61131-2, UL, CE, TUV, UL508, CSA
