Product Description
Honeywell C7035A-1064 Minipeeper Ultraviolet Flame Detector
- Manufacturer: Honeywell
- Series: Flame Safeguard Controls
- Model/Part Number: C7035A-1064
- Description: Minipeeper Ultraviolet Flame Detector for gas, oil, or combination burners
Overview
The Honeywell C7035A-1064 is a Minipeeper Ultraviolet (UV) Flame Detector designed for use with Honeywell flame safeguard controls to provide flame supervision in industrial and commercial burner applications. It detects ultraviolet radiation emitted by combustion flames from gas, oil, or combination gas-oil burners, ensuring reliable and safe operation in environments such as industrial furnaces, boilers, and power plants.
Technical Specifications
| Specification | Details |
|---|---|
| Model | C7035A-1064 |
| Series | Flame Safeguard Controls |
| Type | Ultraviolet Flame Detector (Minipeeper) |
| Function | Detects ultraviolet radiation from combustion flames |
| Application | Gas, oil, or combination gas-oil burners |
| Mounting | Integral collar with internal 1-11-1/2 NPSM threads for 1-inch sighting pipe |
| Lead Length | 72 inches (1.83 meters) |
| Electrical Connection | Two #18 AWG wires, NEC Class 1 |
| Ambient Temperature Range | -40°C to +121°C (-40°F to +250°F) |
| Pressure Rating | Seals against pressures up to 5 psi (34.5 kPa) when correctly installed |
| Environmental Protection | NEMA 3 and NEMA 4 rated (rain-tight, dust-tight) |
| UV Sensor | Field-replaceable ultraviolet sensing tube |
| Compatibility | Honeywell flame safeguard controls (e.g., RA890G, R7249A/B, R7290A, R7749B, R7849A/B amplifiers) |
| Wiring Configuration | Can be wired in parallel for difficult sighting applications |
| Dimensions | Approx. 38 mm diameter x 102 mm length (1.5 x 4 in) |
| Weight | Approx. 0.17 kg (6 oz) |
| Certifications | UL, CSA, FM approved |
| Manual | Honeywell C7027/C7035/C7044/C7927 Minipeeper Product Data (Document 60-2026) |
