Product Description
Product Overview
| Category | Details |
|---|---|
| Manufacturer | Honeywell |
| Model/Part Number | 8C-PDIS01 |
| Description | Digital Input Sequence of Events (SOE) Module designed for Honeywell Experion PKS Series 8 systems, providing 32-channel digital input monitoring with high-resolution event timestamping |
| Key Features | 32 digital input channels, 1 ms SOE resolution, supports 24 VDC inputs, conformal coated, non-redundant, integrates with C300 controllers, high reliability |
Technical Specifications
| Specification | Details |
|---|---|
| Model | 8C-PDIS01 |
| Product Type | Digital Input SOE Module |
| Series | Experion PKS Series 8 |
| Number of Channels | 32 |
| Input Voltage | 24 VDC |
| SOE Resolution | 1 ms |
| Input Current | 4-6 mA per channel |
| Power Supply | 24 VDC (via system backplane) |
| Operating Temperature | -40°C to 70°C (-40°F to 158°F) |
| Weight | Approx. 0.3-0.5 kg (0.66-1.1 lbs) |
External Connection Options
| Connection Type | Details |
|---|---|
| Supported Connections | Terminal blocks for field wiring, connects to Series 8 IOTA via backplane interface |
Functional Features
| Feature | Details |
|---|---|
| Sequence of Events | High-resolution timestamping for precise event logging |
| Environmental Protection | Conformal coating for harsh industrial environments |
| Compatibility | Seamless integration with Experion PKS C300 controllers |
| Diagnostics | Real-time monitoring of input status and module health |
Model and Configuration
| Category | Details |
|---|---|
| Base Model | 8C-PDIS01 |
| Configuration | Non-redundant, conformal coated |
Applications and Benefits
| Category | Details |
|---|---|
| Applications | Process monitoring in oil and gas, chemical, power generation, and manufacturing industries |
| Benefits | Accurate event tracking, reliable input monitoring, durable design, easy integration with DCS systems |
