Product Description
Product Overview
| Category | Details |
|---|---|
| Manufacturer | Honeywell |
| Model/Part Number | 51506303-200 |
| Description | Enhanced Process Network Module (EPNM) designed for Honeywell TDC 3000 systems, providing high-speed communication between Universal Stations and process control networks |
| Key Features | Supports Data Hiway and Local Control Network (LCN), redundant communication paths, high data throughput, compatible with TDC 3000 Universal Stations, conformal coated |
Technical Specifications
| Specification | Details |
|---|---|
| Model | 51506303-200 |
| Product Type | Enhanced Process Network Module (EPNM) |
| Series | TDC 3000 |
| Communication Interface | Data Hiway, Local Control Network (LCN) |
| Data Rate | Up to 1 Mbps |
| Power Supply | 24 VDC (via system backplane) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Dimensions | Approx. 150 x 50 x 200 mm (5.9 x 2.0 x 7.9 in) |
| Weight | Approx. 0.5 kg (1.1 lbs) |
External Connection Options
| Connection Type | Details |
|---|---|
| Supported Connections | Terminal blocks for network wiring, integrates with TDC 3000 Universal Station backplane |
Functional Features
| Feature | Details |
|---|---|
| Network Communication | Facilitates data exchange between Universal Stations and process controllers |
| Redundancy | Supports redundant paths for reliable communication |
| Environmental Protection | Conformal coating for durability in industrial environments |
| Diagnostics | Built-in diagnostics for network status monitoring |
Model and Configuration
| Category | Details |
|---|---|
| Base Model | 51506303-200 |
| Configuration | Standard, conformal coated, non-redundant |
Applications and Benefits
| Category | Details |
|---|---|
| Applications | Process automation in oil and gas, chemical, power generation, and refining industries |
| Benefits | Reliable high-speed networking, seamless TDC 3000 integration, enhanced system uptime, durable design |
