Product Description
Honeywell 51404109-175 TDC 3000 Remote Hardened Multiplexer IOP
Product Overview
- Description: The Honeywell 51404109-175 (MC-PRHM01) is a Remote Hardened Multiplexer Input/Output Processor (IOP) designed for use in Honeywell’s TDC 3000 Distributed Control System (DCS). It processes multiple analog and digital signals from field devices, such as sensors and transmitters
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Honeywell |
| Series | TDC 3000 |
| Model/Part Number | 51404109-175 (MC-PRHM01) |
| Model Type | Remote Hardened Multiplexer Input/Output Processor (IOP) |
| Function | Processes multiple analog and digital signals from field devices in remote or harsh environments |
| Display | Not applicable (no integrated display) |
| Inputs | Multiple analog (e.g., 4–20 mA, 0–10 V) and digital inputs (typically 16–32 channels) |
| Outputs | Data to TDC 3000 system via Local Control Network (LCN) or I/O bus |
| Communication Interfaces | Connects to TDC 3000 system via LCN or proprietary I/O bus |
| Signal Conditioning | Analog-to-digital conversion, signal isolation, multiplexing |
| Accuracy | ±0.1% of full scale (typical for analog inputs) |
| Redundancy | Supports redundant configurations in TDC 3000 systems |
| Diagnostics | Fault detection and diagnostics via TDC 3000 system |
| Compatibility | Honeywell TDC 3000 Distributed Control System |
| Power Supply | 24 VDC (via TDC 3000 backplane, typical) |
| Power Consumption | 10–15 W (estimated, depending on channel count) |
| Environmental Specifications | Operating Temperature: -40°C to +70°C (hardened for harsh environments) Storage Temperature: -40°C to +85°C Relative Humidity: 5% to 95% non-condensing |
| Enclosure | IP65 or higher (designed for harsh environments) |
| Dimensions | Approx. 200 mm (H) x 100 mm (W) x 50 mm (D) (estimated) |
| Weight | 0.5–0.8 kg (approx.) |
| Mounting | Rack-mounted in TDC 3000 cabinet or remote enclosure |
| Certifications | CE, UL, CSA (system-dependent) |
