Product Description
Honeywell 51400993-100 Enhanced Operator Keyboard
- Manufacturer: Honeywell
- Series: TDC 3000
- Model/Part Number: 51400993-100
- Description: Enhanced Operator Membrane Keyboard for TDC 3000 systems
Overview
The Honeywell 51400993-100 is an Enhanced Operator Membrane Keyboard designed for use in Honeywell’s TDC 3000 Distributed Control System (DCS). It serves as a robust human-machine interface (HMI) for operators to interact with the control system, providing reliable input for monitoring and controlling industrial processes in environments such as oil and gas, petrochemical, and power generation facilities.
Technical Specifications
| Specification | Details |
|---|---|
| Model | 51400993-100 |
| Series | TDC 3000 |
| Type | Enhanced Operator Membrane Keyboard |
| Function | Provides operator input for TDC 3000 DCS control and monitoring |
| Key Type | Membrane keys, sealed for dust and moisture resistance |
| Interface | Proprietary Honeywell interface for TDC 3000 operator stations |
| Compatibility | TDC 3000 Universal Control Network (UCN), operator consoles (e.g., Universal Station) |
| Construction | Rugged, industrial-grade materials for harsh environments |
| Operating Temperature | 0°C to +50°C (32°F to +122°F) |
| Storage Temperature | -20°C to +70°C (-4°F to +158°F) |
| Relative Humidity | 5% to 95% (non-condensing) |
| Environmental Protection | Sealed membrane design, resistant to spills, dust, and contaminants |
| Dimensions | Approx. 600 mm x 200 mm x 50 mm (23.6 x 7.9 x 2 in) |
| Weight | Approx. 0.27 kg (0.6 lbs) |
| Certifications | CE, UL, CSA (application-dependent) |
| Manual | TDC 3000 System Manual |
