Product Description
Product Overview
| Category | Details |
|---|---|
| Manufacturer | Honeywell |
| Model/Part Number | 51304540-200 |
| Description | Low Level Analog Input Multiplexer (LLMUX) FTA Board designed for Honeywell TDC 3000 systems, providing termination and signal conditioning for up to 16 low-level analog inputs |
| Key Features | 16-channel analog input, supports thermocouples and RTDs, non-redundant, conformal coated, integrates with TDC 3000 Process Manager, high accuracy signal processing |
Technical Specifications
| Specification | Details |
|---|---|
| Model | 51304540-200 |
| Product Type | Low Level Analog Input FTA Board |
| Series | TDC 3000 |
| Number of Channels | 16 |
| Input Types | Thermocouples (J, K, T, E, etc.), RTDs (Pt100, Ni100), mV |
| Resolution | 16-bit |
| Power Supply | 24 VDC (via system backplane) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Dimensions | Approx. 200 x 100 x 50 mm (7.9 x 3.9 x 2.0 in) |
| Weight | Approx. 0.5 kg (1.1 lbs) |
External Connection Options
| Connection Type | Details |
|---|---|
| Supported Connections | Screw terminal blocks for field wiring, connects to TDC 3000 I/O processor via backplane |
Functional Features
Feature
| Details | |
|---|---|
| Signal Conditioning | Processes low-level signals from thermocouples and RTDs for accurate readings |
| Environmental Protection | Conformal coating for durability in harsh industrial environments |
| Compatibility | Seamless integration with TDC 3000 High Performance Process Manager (HPM) |
| Diagnostics | Supports input signal monitoring and fault detection |
Model and Configuration
| Category | Details |
|---|---|
| Base Model | 51304540-200 |
| Configuration | Non-redundant, conformal coated |
Applications and Benefits
| Category | Details |
|---|---|
| Applications | Temperature monitoring in oil and gas, chemical, power generation, and refining industries |
| Benefits | High accuracy, reliable signal processing, easy integration, durable design for industrial environments |
