| Module Type |
Relay output module |
| Relay Outputs |
8 single-pole changeover (SPCO) relays |
| Relay Contact Rating |
5 A at 250 V AC or 30 V DC |
| Relay Operation |
Configurable: latching/non-latching, energized/de-energized |
| Power Supply |
18 to 32 V DC via System 57 rack |
| Power Consumption |
2.0 W typical |
| Connections |
Screw terminals for field wiring (up to 2.5 mm², 14 AWG) |
| Dimensions |
1-inch wide (25.4 mm), fits System 57 rack slot |
| Weight |
180 g |
| Operating Temperature |
-20°C to 70°C (-4°F to 158°F) |
| Standards Compliance |
CE, UL, CSA |
