Product Description
Product Overview
| Category | Details |
|---|---|
| Manufacturer | Honeywell |
| Model/Part Number | 10310/1/1 |
| Description | Earth Leakage Detector (ELD) designed for Honeywell Safety Manager systems, providing continuous monitoring of earth leakage currents in 24 VDC systems to enhance electrical safety |
| Key Features | High sensitivity for detecting minimal leakage currents, manual self-test, earth connection monitor, rail-mounted, supports 24 VDC systems, continuous or pulsed operation modes, compact design |
Technical Specifications
| Specification | Details |
|---|---|
| Model | 10310/1/1 |
| Product Type | Earth Leakage Detector (ELD) |
| Series | Safety Manager |
| Operating Voltage | 16-32 VDC (nominal 24 VDC) |
| Supply Current | Max. 60 mA |
| Max. Earth Current | 25.0 mA (± 5 mA) |
| Output Voltage | Max. 115 VDC |
| Output Current | Max. 2 A |
| Switched Load | Max. 100 W / 1000 VA |
| Operating Temperature | -25°C to 60°C (-13°F to 140°F) |
| Dimensions | Approx. 100 x 46 x 70 mm (3.94 x 1.81 x 2.76 in) |
| Weight | Approx. 0.2 kg (0.44 lbs) |
External Connection Options
| Connection Type | Details |
|---|---|
| Supported Connections | Screw terminals for power, earth, and output connections, DIN rail mounting for integration with control panels |
Functional Features
| Feature | Details |
|---|---|
| Fault Detection | Monitors earth leakage currents to prevent electrical hazards |
| Operation Modes | Continuous (DC) or pulsed (1 Hz, 0.25 Hz) connection to earth |
| Self-Test | Manual self-test via switch for operational verification |
| Indicator | Green MODE LED flashes at selected frequency in pulsed modes |
Model and Configuration
| Category | Details |
|---|---|
| Base Model | 10310/1/1 |
| Configuration | Rail-mounted, non-customized, standard ELD for 24 VDC systems |
Applications and Benefits
| Category | Details |
|---|---|
| Applications | Electrical safety in oil and gas, chemical, manufacturing, and power generation industries |
| Benefits | Enhanced safety, reliable fault detection, easy installation, compact footprint, compliance with industrial standards |
