Product Description
🔍
Product Overview
|
Field |
Details |
|---|---|
|
Manufacturer |
Honeywell |
|
Model/Part Number |
10102/1/1 |
|
Description |
4-Channel Analog Input Module (Voltage/Current) |
|
Approvals |
CE, TÜV, UL |
|
Software Versions |
Compatible with all |
|
Space Requirements |
4 TE, 3 HE (≈ 4 HP, 3U) |
⚙️
Technical Specifications
|
Category |
Specification |
|---|---|
|
Power Requirements |
5 VDC @ 30 mA24 VDC @ 175 mA + 25 mA per active input |
|
Input Channels |
4 |
|
Input Types |
Voltage: 0–10 V / 2–10 VCurrent: 0–20 mA / 4–20 mA |
|
Input Resistance |
Voltage: 12.5 kΩCurrent: 100 Ω |
|
Loop Power Supply |
26 VDC (±1 V), short-circuit protected |
|
Loop Current Limit |
> 20 mA (solid state protected) |
|
Max Loop Resistance |
1 kΩ |
|
A/D Converter |
12-bit |
|
Accuracy |
≤ 0.75% |
|
Max Input Signal |
–150% to +200% of selected range |
🔧
Physical & Mechanical
|
Parameter |
Details |
|---|---|
|
Key Coding |
Module Hole: A27Pins: C3, C19, C27 |
|
Rack Key Coding |
Blind Stops: C11, C23, C31Large Pin: A27 |
