Product Description
Product Overview
| Category | Details |
|---|---|
| Manufacturer | Honeywell |
| Model/Part Number | 10020/1/2 |
| Description | Quad Processor Module (QPM) designed for Honeywell Fail-Safe Controller (FSC) systems, providing high-performance processing for safety-critical automation applications |
| Key Features | Four independent processors, SIL 3 certified, flash memory, self-diagnostic capabilities, conformal coated, supports FSC system operations, high reliability |
Technical Specifications
| Specification | Details |
|---|---|
| Model | 10020/1/2 |
| Product Type | Quad Processor Module (QPM) |
| Series | FSC (Fail-Safe Controller) |
| Processors | Four independent processors |
| Memory | Flash memory |
| Safety Integrity Level | SIL 3 (IEC 61508) |
| Power Supply | 24 VDC (via system backplane) |
| Operating Temperature | -25°C to 60°C (-13°F to 140°F) |
| Dimensions | Approx. 172 mm x 102 mm x 41 mm (6.77 in x 4.02 in x 1.61 in) |
| Weight | Approx. 0.5 kg (1.1 lbs) |
External Connection Options
| Connection Type | Details |
|---|---|
| Supported Connections | Backplane interface for FSC system rack, integrates with I/O modules and communication cards |
Functional Features
| Feature | Details |
|---|---|
| Processing | Executes safety logic and control functions for FSC system |
| Diagnostics | Self-diagnostic routines for hardware and software monitoring |
| Environmental Protection | Conformal coating for harsh industrial environments |
| Safety | Designed with Failure Mode Effect Analysis (FMEA) principles for SIL 3 compliance |
Model and Configuration
| Category | Details |
|---|---|
| Base Model | 10020/1/2 |
| Configuration | Standard, conformal coated, flash memory-based |
Applications and Benefits
| Category | Details |
|---|---|
| Applications | Safety-critical automation in oil and gas, chemical, power generation, and manufacturing industries |
| Benefits | High processing reliability, SIL 3 safety compliance, robust diagnostics, durable design, seamless FSC system integration |
