Product Description
05701-A-0121 Parameters
Product Overview
| Parameter | Details |
|---|---|
| Part Number | 05701-A-0121 |
| Product Name | Engineering Interface Software |
| Application | Configuration and diagnostics for System 57 Control System |
| Compatibility | Used with Engineering Card (05701-A-0361) and Engineering Interface Lead (05701-A-0120) |
| Function | Facilitates complex configuration and maintenance of the 5704F Control System via RS232 link |
| System Requirement | IBM compatible personal computer |
Functional Specifications
| Parameter | Details |
|---|---|
| Serial Port Settings | 9600 Baud, 8 Data Bits, No Parity, 1 Stop Bit |
| Output Format | ASCII text for rack summary and card configuration/diagnostic printouts |
| Supported Operations | - Rack summary printout - Card configuration and diagnostic printout - Clock and calendar setting (via Engineering Card) |
| Dependencies | Requires Engineering Interface Lead (05701-A-0120) for connection to RS232 serial printers or PC terminal programs (e.g., Windows 95 Hyper Terminal) |
