Product Description
Product Overview
| Field | Details |
|---|---|
| Manufacturer | Honeywell Analytics |
| Part Number | 04230-A-1025 |
| Product Type | SHC Protection Device Module and Lead |
| Function | Provides protection for gas detection systems |
| System Compatibility | Searchpoint Optima Plus, Searchline Excel, Searchline Excel Cross-Duct |
Functional Specifications
| Feature | Specification |
|---|---|
| Purpose | Protects gas detectors from electrical surges and environmental conditions |
| Compatibility | Interfaces with Searchpoint Optima Plus and Searchline Excel infrared gas detectors |
| Connection | Includes lead for direct connection to compatible gas detectors |
| Diagnostics | Supports fault indication for connected gas detectors |
| Applications | Used in flammable gas detection for industrial environments (e.g., oil and gas, chemical processing) |
Electrical Specifications
| Parameter | Specification |
|---|---|
| Input Voltage | Compatible with 24 VDC systems (typical for connected gas detectors) |
| Protection Features | Surge protection, environmental sealing |
Environmental Specifications
| Parameter | Specification |
|---|---|
| Operating Temperature | -40°C to 65°C (-40°F to 149°F) |
| Storage Temperature | -40°C to 80°C (-40°F to 176°F) |
| Relative Humidity | Operating: 0% to 95% non-condensing |
| Ingress Protection | IP66/IP67 (when installed with compatible gas detectors) |
Physical Specifications
| Parameter | Specification |
|---|---|
| Mounting | Direct connection to compatible gas detectors |
| Weight | 0.5 kg (approximate) |
| Material | Corrosion-resistant housing for harsh environments |
