Product Description
General Information
|
Item |
Details |
|---|---|
|
Manufacturer |
HIMA |
|
Model/Part Number |
F9404 |
Description
|
Item |
Details |
|---|---|
|
Type |
Power Supply Module |
|
Application |
Provides redundant, regulated 24 V DC power for HIMA safety-related automation systems, ensuring reliable operation of I/O and controller modules |
Specifications
|
Category |
Details |
|---|---|
|
Input Voltage |
24 V DC nominal (19–30 V DC operating range) |
|
Output Voltage |
24 V DC regulated |
|
Output Current |
Up to 10 A continuous |
|
Efficiency |
≥ 85 % typical |
|
Isolation |
Galvanic isolation between input and output |
|
Protection |
Over-voltage, short-circuit, and thermal shutdown |
|
Redundancy |
Designed for parallel operation to support system power redundancy |
|
Diagnostics |
Status and fault indication LEDs |
|
Power Consumption |
Approx. 20 W internal (typical) |
Environmental Limits
|
Parameter |
Details |
|---|---|
|
Operating Temperature |
0 to +60 °C |
|
Storage Temperature |
–40 to +85 °C |
|
Relative Humidity |
5 to 95 % non-condensing |
|
Vibration |
Meets industrial vibration and shock standards |
|
EMC |
Complies with EN 61000-6-2 and EN 61000-6-4 |
Physical Characteristics
|
Parameter |
Details |
|---|---|
|
Dimensions |
Approx. 128 mm × 25 mm × 120 mm |
|
Mounting |
DIN-rail |
|
Weight |
About 150 g |
|
Connections |
Plug-in terminal blocks for field wiring |
Ordering Information
|
Item |
Details |
|---|---|
|
Model Number |
F9404 |
|
Accessories |
Terminal blocks and system backplane connectors ordered separately |
