Product Description
Product Details
|
Manufacturer |
HIMA |
|---|---|
|
Model/Part Number |
F2DO401 |
|
Description |
Safety-Related Controller |
Technical Specifications
General
|
Parameter |
Value |
|---|---|
|
Response Time |
≥ 20 ms |
|
Ethernet Interfaces |
2 x RJ-45, 10BASE-T/100BASE-Tx with integrated switch |
|
Operating Voltage |
24 VDC, -15…+20 %, rPP ≤ 15 % (from a power supply unit with safe insulation in accordance with IEC 61131-2) |
|
Fuse (External) |
10 A time-lag (T) |
|
Operating Temperature |
0…+60 °C |
|
Storage Temperature |
-40…+85 °C |
|
Type of Protection |
IP20 |
|
Max. Dimensions (Without Plug) |
Width: 152 mm (with housing screws) | Height: 114 mm (with fixing bolt) | Depth: 66 mm (with earthing screw) |
|
Weight |
0.8 kg |
Digital Outputs
|
Parameter |
Value |
|---|---|
|
Number of Outputs |
4 (non-galvanically separated) |
|
Total Current Permitted for All Output Channels |
Max. 20 A |
|
Output Voltage |
≥ L+ minus 1 V |
|
Output Current |
Max. 5 A |
|
Lamp Load |
Max. 60 W |
|
Inductive Load |
Max. 500 mH |
|
Internal Voltage Drop |
Max. 1 V at 5 A |
|
Leakage Current (with Low Level) |
Max. 1 mA at 1 V |
|
Behavior Upon Overload |
The affected output is switched off and cyclically switched on again |
