Product Description
HIMA 98 4323603 Logic Function Module
Product Overview
- The HIMA 98 4323603 is a Logic Function Module, specifically the F 3236 model, designed for HIMA safety instrumented systems (SIS). This digital input module processes signals from field devices, such as sensors and switches, in safety-critical applications, ensuring reliable operation within HIMA's programmable electronic systems (PES). It is used in industries like oil and gas, chemical, and power generation, supporting safety functions compliant with high safety integrity levels.
Technical Specifications
- The 98 4323603 (F 3236) has the following specifications based on industry documentation and related HIMA modules:
| Specification | Details |
|---|---|
| Model/Part Number | 98 4323603 (F 3236) |
| Manufacturer | HIMA |
| Description | Logic Function Module (Digital Input) |
| Input Type | Digital, 24 VDC |
| Channel Capacity | 16 channels |
| Input Voltage Range | 18–30 VDC |
| Operating Voltage | 24 VDC |
| Power Consumption | Approx. 5 W |
| Space Requirement | 4 TE (4 HP, Horizontal Pitch) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Weight | Approx. 0.3 kg |
Additional Details
- The 98 4323603 (F 3236) includes the following additional information based on its standard use and documentation:
- Function: Processes digital input signals from field devices, enabling logic functions for safety-critical control; supports line monitoring for detecting open or short circuits; integrates with HIMA PES for safety logic execution.
- Compatibility: Compatible with HIMA H41q and H51q systems; interfaces with coupling modules like F7553 and termination panels for field wiring; suitable for use with distributed control systems (DCS).
- Configuration: Configured via HIMA’s ELOP II or SILworX software for programming and diagnostics; supports automatic testing during operation; designed for rack mounting in HIMA subracks.
- Certifications: Certified to IEC 61508 for Safety Integrity Level 3 (SIL3) and EN ISO 13849-1 Category 4; complies with industrial standards for hazardous environments.
