HIMA 98 4180105 Planar4 Logic Function Module
Product Overview
- The HIMA 98 4180105, identified as a Planar4 Logic Function Module (F 1810), is a safety-related digital logic module designed for HIMA safety instrumented systems (SIS). This module processes digital input signals and executes logic operations for safety-critical applications within HIMA’s programmable electronic systems (PES). It is used in industries such as oil and gas, chemical, and power generation, ensuring reliable operation compliant with high safety integrity levels.
Technical Specifications
- The 98 4180105 (F 1810) has the following specifications based on industry documentation for the Planar4 series and related HIMA modules:
| Specification | Details |
|---|---|
| Model/Part Number | 98 4180105 (F 1810) |
| Manufacturer | HIMA |
| Description | Planar4 Logic Function Module |
| Function | Digital logic processing (AND, OR, NOT, etc.) |
| Input Type | Digital, 24 VDC |
| Operating Voltage | 24 VDC |
| Power Consumption | Approx. 2–3 W |
| Space Requirement | 4 TE (4 HP, Horizontal Pitch) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Weight | Approx. 0.2 kg |
Additional Details
- The 98 4180105 (F 1810) includes the following additional information based on its standard use and documentation for the Planar4 series:
- Function: Executes digital logic operations (e.g., AND, OR, NOT) for safety-critical control, processing input signals from field devices to generate appropriate safety responses; supports fault-tolerant logic execution.
- Compatibility: Compatible with HIMA Planar4 systems and H41q/H51q PES; integrates with modules like F 3236 (digital input) and F 6705 (analog comparator) in HIMA subracks; interfaces with coupling modules like F7553.
- Configuration: Configured via HIMA’s ELOP II or SILworX software for programming logic functions and diagnostics; supports automatic self-testing during operation; designed for rack mounting in HIMA subracks.
