General Electric UR8ZH Multilin Universal Relay Digital I/O Module
Product Overview
- Description: The General Electric UR8ZH is a digital I/O module designed for use in GE’s Multilin Universal Relay (UR) series, such as the T60, L90, or F60 relays.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | General Electric |
| Series | Multilin Universal Relay (UR) |
| Model/Part Number | UR8ZH |
| Model Type | Digital I/O Module |
| Function | Provides digital inputs and outputs for control and monitoring |
| Display | LED indicators (input/output status, module status) |
| Inputs | 8 digital inputs (configurable, typically 24–125 VDC) |
| Outputs | 8 digital outputs (Form-C or Form-A relays, configurable, typically 24–125 VDC) |
| Communication Interfaces | Interfaces via UR relay backplane |
| Signal Conditioning | Internal signal isolation, debouncing for inputs |
| Accuracy | Not applicable (discrete signal processing) |
| Redundancy | Supports redundant configurations in UR relays |
| Diagnostics | LED status indicators, fault reporting via relay diagnostics |
| Compatibility | Multilin UR series relays (e.g., T60, L90, D60, F60) |
| Power Supply | Powered via UR relay backplane (5 VDC, 24 VDC) |
| Power Consumption | 5 W typical, 10 W max |
| Environmental Specifications | Operating Temperature: -40°C to +60°C Storage Temperature: -40°C to +80°C Relative Humidity: 5% to 95% non-condensing |
| Enclosure | IP40 (when installed in relay chassis) |
| Dimensions | Approx. 100 mm (H) x 50 mm (W) x 150 mm (D) |
| Weight | 0.4 kg (approx.) |
| Mounting | Plugs into Multilin UR relay chassis |
| Certifications | CE, UL, cULus, IEC 60255 |
