Product Description
Product Details
| Parameter | Details |
|---|---|
| Manufacturer | General Electric |
| Model/Part Number | IS220PSVOH1A |
| Description | Power Supply Module |
Product Overview
| Parameter | Details |
|---|---|
| Part Number | IS220PSVOH1A |
| Product Name | IS220PSVOH1A Power Supply Module |
| Application | Power supply for turbine control systems in power generation and industrial applications |
| Compatibility | Designed for GE Mark VIe and Mark VIeS control systems; interfaces with I/O modules and control processors |
| Function | Provides regulated DC power for reliable operation of control components, supports redundancy and fault tolerance |
Functional Specifications
| Parameter | Details |
|---|---|
| Input Voltage | 125 V DC nominal (95-140 V DC) |
| Output Voltage | +5 V DC, +24 V DC, -5 V DC rails |
| Output Current | 10 A at +5 V, 2 A at +24 V, 0.5 A at -5 V |
| Power Rating | 100 W maximum |
| Efficiency | >80% at full load |
| Isolation | Input-output isolation 1500 V DC |
| Operating Temperature Range | -30°C to +70°C |
| Mounting | Rack mount in control cabinet |
| Dimensions | 10.5" x 8.5" x 1.5" (267 mm x 216 mm x 38 mm) approximate |
| Weight | 2.5 lb (1.13 kg) |
| Protection Features | Overvoltage, overcurrent, short-circuit protection |
| Standards Compliance | IEC 61131-2, CE, UL, CSA |
