Product Description
General Information
- Manufacturer: General Electric
- Model/Part Number: IS220PRTDH1B
- Description: The General Electric IS220PRTDH1B is a Resistance Temperature Detector (RTD) Input Module from the Mark VIe series, designed for use in GE’s Speedtronic turbine control systems. This I/O pack serves as an electrical interface between one or two I/O Ethernet networks and an RTD input terminal board, supporting up to 8 RTD inputs for precise temperature monitoring. It includes a processor board common to all Mark VIe distributed I/O packs and an acquisition board tailored for RTD signals, making it critical for turbine control in industrial applications.
Technical Specifications
| Specification | Details |
|---|---|
| Type | RTD Input Module |
| Series | Mark VIe Speedtronic |
| Inputs | 8 RTD inputs |
| Communication | Dual RJ45 Ethernet ports (IONet), 3-pin power input |
| Output | DC-37 pin connector |
| Power Requirements | 28 V DC nominal |
| Operating Temperature | -30°C to +65°C |
| Weight | 0.43 kg (0.95 lbs) |
| Application | Turbine control and temperature monitoring in industrial power generation |
