Product Description
General Electric IS215WETAH1A Mark VIe Wind Turbine Control Board
- Manufacturer: General Electric (now under GE Vernova)
- Series: Mark VIe Speedtronic
- Model/Part Number: IS215WETAH1A
- Description: Wind Turbine Control Board for wind turbine control in Mark VIe Speedtronic systems
Overview
The General Electric IS215WETAH1A is a Wind Turbine Control Board from the Mark VIe Speedtronic series, manufactured by GE and now managed by GE Vernova. Designed for industrial automation, it serves as a critical component in wind turbine control systems, managing control logic and interfacing with sensors and actuators to optimize turbine performance. It supports both simplex and Triple Modular Redundant (TMR) configurations and is used in renewable energy applications, particularly wind power generation, to ensure efficient and reliable turbine operation.
Technical Specifications
| Specification | Details |
|---|---|
| Model | IS215WETAH1A |
| Series | Mark VIe Speedtronic |
| Type | Wind Turbine Control Board (WETA) |
| Function | Processes control logic and manages I/O for wind turbine control |
| Inputs/Outputs | Analog and digital I/O for sensors (e.g., wind speed, blade pitch) and actuators |
| Communication | Ethernet (IONet), supports ControlST protocols |
| Connectors | Multi-pin connectors for I/O modules, terminal blocks for field connections |
| Power Supply | 24 VDC, supplied by Mark VIe system |
| Signal Protection | EMI shielding, surge suppression |
| Components | Surface-mount technology, microprocessors, integrated circuits, resistors, capacitors |
| Power Consumption | Approx. 1–2 A at 5 VDC (typical for Mark VIe modules, not publicly specified) |
| Board Size | Approx. 15.9 cm x 17.8 cm (6.26 x 7.01 in) |
| Coating | Conformal coating for environmental protection |
| Board Markings | GE logo, IS215WETAH1A, 6BA01 code |
| Operating Temperature | -30°C to +65°C (-22°F to +149°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Relative Humidity | 5% to 95% (non-condensing) |
| Weight | Approx. 0.5 kg (1.1 lbs) |
| Mounting | Single slot in Mark VIe rack, DIN-rail or panel mount |
| Certifications | CE, UL, CSA, Class I Div 2 |
| Compatibility | Mark VIe/Mark VIeS Turbine Control System, ToolboxST software |
| Manual | GEH-6721L |
