General Electric IS215AEPAH1C Wind Pitch Amplifier Board
Product Overview
- Description: The General Electric IS215AEPAH1C is a wind pitch amplifier board designed for use in GE’s Mark VIe turbine control systems, specifically for wind turbine applications. It amplifies and processes signals for controlling pitch actuators
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | General Electric |
| Series | Mark VIe |
| Model/Part Number | IS215AEPAH1C |
| Model Type | Wind Pitch Amplifier Board |
| Function | Amplifies and processes signals for wind turbine pitch actuators |
| Display | LED indicators (status, power, fault) |
| Inputs | Control signals from Mark VIe system (analog/digital) |
| Outputs | Amplified control signals to pitch actuators (e.g., 4–20 mA, 0–10 V) |
| Communication Interfaces | Mark VIe system backplane, IONet |
| Signal Conditioning | Internal signal amplification, digital-to-analog conversion |
| Accuracy | ±0.1% of full scale (typical for analog signals) |
| Resolution | 16 bits (typical) |
| Redundancy | Supports redundancy in Mark VIe configurations |
| Diagnostics | LED status indicators, fault reporting to control system |
| Compatibility | GE Mark VIe turbine control systems (wind turbine applications) |
| Power Supply | 5 VDC, 24 VDC (from Mark VIe backplane), external power for actuators |
| Power Consumption | 10 W max (typical, excluding actuator power) |
| Environmental Specifications | Operating Temperature: -30°C to +65°C Storage Temperature: -40°C to +85°C Relative Humidity: 5% to 95% non-condensing |
| Enclosure | IP20 (open, mounted in control cabinet) |
| Dimensions | Approx. 200 mm (H) x 100 mm (W) x 40 mm (D) |
| Weight | 0.5 kg (approx.) |
| Mounting | Plugs into Mark VIe control rack |
| Certifications | CE, UL, cULus, RoHS |
