Product Description
General Electric IS210MACCH1AKH Mark VIe Main ACS Control Card
- Manufacturer: General Electric (now under GE Vernova)
- Series: Mark VIe Speedtronic
- Model/Part Number: IS210MACCH1AKH
- Description: Main ACS Control Card for turbine control in Mark VIe Speedtronic systems
Overview
The General Electric IS210MACCH1AKH is a Main ACS (Application Control System) Control Card from the Mark VIe Speedtronic series, manufactured by GE and now managed by GE Vernova. Designed for industrial automation, it serves as a critical component in turbine control systems, processing control logic and interfacing with actuators and sensors for gas and steam turbines. It supports simplex and Triple Modular Redundant (TMR) configurations and is used in power generation, oil and gas, and industrial manufacturing to ensure precise and reliable turbine operation.
Technical Specifications
| Specification | Details |
|---|---|
| Model | IS210MACCH1AKH |
| Series | Mark VIe Speedtronic |
| Type | Main ACS Control Card (MACC) |
| Function | Processes control logic and manages I/O for turbine control |
| Inputs/Outputs | Analog and digital I/O via terminal boards |
| Connectors | Multi-pin connectors for I/O modules, terminal blocks for field connections |
| Power Supply | 24 VDC or 125 VDC, supplied by Mark VIe system |
| Signal Protection | EMI shielding, surge suppression |
| Components | Surface-mount technology, microprocessors, memory chips, integrated circuits |
| Power Consumption | Approx. 1–2 A at 5 VDC (typical for Mark VIe modules, not publicly specified) |
| Board Size | Approx. 15.9 cm x 17.8 cm (6.26 x 7.01 in) |
| Coating | Conformal coating for environmental protection |
| Board Markings | GE logo, IS210MACCH1AKH, 6BA01 code |
| Operating Temperature | -30°C to +65°C (-22°F to +149°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Relative Humidity | 5% to 95% (non-condensing) |
| Weight | Approx. 0.5 kg (1.1 lbs) |
| Mounting | Single slot in Mark VIe rack, DIN-rail or panel mount |
| Certifications | CE, UL, CSA, Class I Div 2 |
| Compatibility | Mark VIe Turbine Control System, ToolboxST Software Suite |
| Manual | GEH-6721L |
