General Electric IS210BPPCH1AEC (IS215AEPCH1EB) Wind Pitch Control Board
Product Overview
- Description: The General Electric IS210BPPCH1AEC, also referenced as IS215AEPCH1EB, is a wind pitch control board designed for use in GE’s Mark VIe turbine control systems, specifically for wind turbine applications.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | General Electric |
| Series | Mark VIe |
| Model/Part Number | IS210BPPCH1AEC (IS215AEPCH1EB) |
| Model Type | Wind Pitch Control Board |
| Function | Controls wind turbine blade pitch for performance and safety |
| Display | LED indicators (status, power, fault) |
| Inputs | Analog and digital signals from pitch sensors (e.g., position, speed) |
| Outputs | Control signals to pitch actuators/motors |
| Communication Interfaces | Mark VIe system backplane, IONet, Ethernet (for ControlST) |
| Signal Conditioning | Internal analog-to-digital conversion, signal processing |
| Accuracy | ±0.1% of full scale (typical for analog signals) |
| Resolution | 16 bits (typical) |
| Redundancy | Supports redundancy in Mark VIe configurations |
| Diagnostics | LED status indicators, fault reporting to control system |
| Compatibility | GE Mark VIe turbine control systems (wind turbine applications) |
| Power Supply | 5 VDC, 24 VDC (from Mark VIe backplane) |
| Power Consumption | 8 W max (typical) |
| Environmental Specifications | Operating Temperature: -30°C to +65°C Storage Temperature: -40°C to +85°C Relative Humidity: 5% to 95% non-condensing |
| Enclosure | IP20 (open, mounted in control cabinet) |
| Dimensions | Approx. 200 mm (H) x 100 mm (W) x 40 mm (D) |
| Weight | 0.5 kg (approx.) |
| Mounting | Plugs into Mark VIe control rack |
| Certifications | CE, UL, cULus, RoHS |
