| Specification |
Details |
| Model |
IS210BAPAH1A |
| Series |
Mark VI Speedtronic |
| Type |
Analog Processor Module (BAPA) |
| Function |
Processes analog signals for turbine control and monitoring |
| Input Voltage |
125 V DC |
| Output Voltage |
24 V DC |
| Analog Inputs |
4–20 mA, 0–10 V (configurable) |
| Analog Outputs |
0–20 mA |
| Connectors |
Terminal blocks for field connections, multi-pin connectors for system integration |
| Signal Protection |
Surge suppression, EMI filtering |
| Components |
Surface-mount technology, integrated circuits, resistors, capacitors, transistors |
| Power Consumption |
Approx. 1–2 A at 5 VDC (typical for Mark VI modules, not publicly specified) |
| Board Size |
Approx. 6 cm x 13 cm x 8.3 cm (2.4 x 5.1 x 3.3 in) |
| Coating |
Conformal coating for environmental protection |
| Board Markings |
GE logo, IS210BAPAH1A, 6BA01 code |
| Operating Temperature |
-30°C to +65°C (-22°F to +149°F) |
| Storage Temperature |
-40°C to +85°C (-40°F to +185°F) |
| Relative Humidity |
5% to 95% (non-condensing) |
| Weight |
Approx. 0.38 kg (0.84 lbs) |
| Mounting |
DIN-rail or panel mount in Mark VI rack |
| Certifications |
CE, UL, CSA, Class I Div 2 |
| Compatibility |
Mark VI Turbine Control System, Proficy Machine Edition software |
| Manual |
GEH-6421 |
