| Specification |
Details |
| Model |
IS200TBCIS2C |
| Series |
Mark VIe Speedtronic |
| Type |
Discrete Input Terminal Board (TBCI) |
| Function |
Processes 24 dry contact inputs for discrete signal monitoring |
| Input Capacity |
24 dry contact inputs, optic-isolated |
| Input Current |
2.5 mA (first 21 inputs), 10 mA (last 3 inputs) |
| Power Supply |
Floating 24 VDC from turbine control assembly |
| Connectors |
Two terminal blocks (TB1, TB2, each with 24 terminals), 3 multi-pin connectors (JR1, JS1, JT1 for TMR) |
| I/O Pack Compatibility |
PDIA (IS220PDIAH1A) for Mark VIe, YDIA for Mark VIeS |
| Signal Protection |
Filters for high-frequency noise suppression, surge protection |
| Components |
Surface-mount technology, 5 red capacitors, terminal blocks, resistors, integrated circuits |
| Power Consumption |
10 W at 24 VDC |
| Board Size |
11 cm x 6 cm x 6.7 cm (4.33 x 2.36 x 2.64 in) |
| Coating |
S-style PCB coating (conformal) for environmental protection |
| Board Markings |
GE logo, IS200TBCIS2C, 6BA01 code |
| Operating Temperature |
-40°C to +85°C (-40°F to +185°F) |
| Storage Temperature |
-40°C to +85°C (-40°F to +185°F) |
| Relative Humidity |
5% to 95% (non-condensing) |
| Weight |
Approx. 1 kg (2.2 lbs) |
| Mounting |
Single slot in Mark VIe rack, side-mounting brackets for I/O packs |
| Certifications |
CE, UL, CSA, Class I Div 2, safety-certified for Mark VIeS |
| Compatibility |
Mark VIe/VIeS Turbine Control System, VCCC, VCRC, ToolboxST software |
| Manual |
GEH-6721L |
