General Electric IS200STAIH1A Simplex Analog Input Terminal Board
Product Overview
- Description: The General Electric IS200STAIH1A is a simplex analog input terminal board designed for use in GE’s Mark VIe turbine control systems. It interfaces with analog sensors to process signals such as voltage or current inputs
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | General Electric |
| Series | Mark VIe |
| Model/Part Number | IS200STAIH1A |
| Model Type | Simplex Analog Input Terminal Board |
| Function | Interfaces analog sensors for signal processing |
| Display | LED indicators (status, power) |
| Inputs | 10 analog inputs (configurable, typically 4–20 mA or 0–10 V) |
| Outputs | Digital data to Mark VIe control system |
| Communication Interfaces | Mark VIe system backplane |
| Signal Conditioning | Internal analog-to-digital conversion, signal isolation |
| Accuracy | ±0.1% of full scale (typical) |
| Resolution | 16 bits (typical) |
| Redundancy | Non-redundant (simplex configuration) |
| Diagnostics | LED status indicators, fault reporting to control system |
| Compatibility | GE Mark VIe turbine control systems |
| Power Supply | 5 VDC, 24 VDC (from Mark VIe backplane) |
| Power Consumption | 5 W max (typical) |
| Environmental Specifications | Operating Temperature: -30°C to +65°C Storage Temperature: -40°C to +85°C Relative Humidity: 5% to 95% non-condensing |
| Enclosure | IP20 (open, mounted in control cabinet) |
| Dimensions | Approx. 200 mm (H) x 100 mm (W) x 40 mm (D) |
| Weight | 0.5 kg (approx.) |
| Mounting | Plugs into Mark VIe control rack |
| Certifications | CE, UL, cULus, RoHS |
