Product Description
General Electric IC693PWR324Z Power Supply Module
Product Overview
- Description: The General Electric IC693PWR324Z is a power supply module designed for use with GE Fanuc Series 90-30 PLC systems. It provides regulated DC power to the Series 90-30 backplane, supporting CPU, I/O
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | General Electric |
| Series | Series 90-30 |
| Model/Part Number | IC693PWR324Z |
| Model Type | Power Supply Module |
| Function | Provides DC power to Series 90-30 PLC backplane |
| Display | LED indicators (power, status) |
| Inputs | 100–240 VAC (47–63 Hz) or 24 VDC |
| Outputs | 5 VDC (5 A max), 24 VDC relay (0.6 A max), 24 VDC isolated (0.4 A max) |
| Communication Interfaces | None (power supply only) |
| Signal Conditioning | Internal voltage regulation, overcurrent, and overvoltage protection |
| Accuracy | ±5% voltage regulation |
| Redundancy | Non-redundant |
| Diagnostics | LED status indicators, fault reporting to PLC |
| Compatibility | GE Fanuc Series 90-30 PLC systems |
| Power Supply | Input: 100–240 VAC (30 W max) or 24 VDC (40 W max) |
| Power Consumption | 30 VA (AC) or 40 W (DC) max |
| Environmental Specifications | Operating Temperature: 0°C to +60°C Storage Temperature: -40°C to +85°C Relative Humidity: 5% to 95% non-condensing |
| Enclosure | IP20 (open, mounted in PLC rack) |
| Dimensions | 130 mm (H) x 35 mm (W) x 100 mm (D) |
| Weight | 0.4 kg |
| Mounting | Plugs into Series 90-30 PLC rack |
| Certifications | CE, UL, cULus, RoHS |
