General Electric IC693MDL740 Discrete Output Module
Product Overview
- Description: The General Electric IC693MDL740 is a discrete output module designed for use with GE Fanuc Series 90-30 PLC systems. It provides 16 positive logic output channels for controlling external devices such as relays
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | General Electric |
| Series | Series 90-30 |
| Model/Part Number | IC693MDL740 |
| Model Type | Discrete Output Module |
| Function | Controls external devices via discrete DC output signals |
| Display | LED indicators (status, power, output state) |
| Inputs | Digital data from Series 90-30 PLC |
| Outputs | 16 positive logic DC outputs (12/24 VDC, 0.5 A per point) |
| Communication Interfaces | Series 90-30 backplane interface |
| Signal Conditioning | Internal signal isolation |
| Accuracy | Not applicable |
| Redundancy | Non-redundant |
| Diagnostics | LED status indicators, fault reporting to PLC |
| Compatibility | GE Fanuc Series 90-30 PLC systems |
| Power Supply | 5 VDC (from Series 90-30 backplane), 12/24 VDC (external for outputs) |
| Power Consumption | 110 mA at 5 VDC max |
| Environmental Specifications | Operating Temperature: 0°C to +60°C Storage Temperature: -40°C to +85°C Relative Humidity: 5% to 95% non-condensing |
| Enclosure | IP20 (open, mounted in PLC rack) |
| Dimensions | 130 mm (H) x 35 mm (W) x 100 mm (D) |
| Weight | 0.3 kg |
| Mounting | Plugs into Series 90-30 PLC rack |
| Certifications | CE, UL, cULus, RoHS |
