GE IC693APU302P Series 90-30 Axis Positioning Module

Quantity

General Electric IC693APU302P Series 90-30 Axis Positioning Module

Manufacturer: General Electric (now under Emerson Automation)
Series: Series 90-30
Model/Part Number: IC693APU302P
Description: 2-Axis Positioning Module (APM) for motion and position control in industrial automation systems

The General Electric IC693APU302P is a dual-axis positioning module (APM) from the Series 90-30 Programmable Logic Controller (PLC) platform, originally manufactured by GE Fanuc and now managed by Emerson Automation. Designed for industrial automation, it controls two servo motor axes for precise motion and position control, integrating high-performance control with PLC logic. It is suitable for applications in manufacturing, CNC machinery, and material handling. The "-P" revision indicates a specific firmware or hardware update.

Specification	Details
Model	IC693APU302P
Series	Series 90-30
Type	Axis Positioning Module (APM)
Axes	2 independent motion axes
Operating Modes	Standard mode, Follower mode (electronic gearing)
Connectors	Two 9-pin D-shell connectors (one per axis), two 24-pin high-density connectors (servo connections)
Resolution	Configurable, based on servo drive feedback
Motion Programs	Up to 10 per module, stored in APM memory
Power Consumption	800 mA at +5 VDC from backplane
Isolation	1500 VAC (field-to-logic)
CPU Compatibility	Series 90-30 CPUs 311, 313, 323, or higher (modular CPU 331 or above for multiple modules)
Max Modules per System	8 (with CPU 331 or higher), max 3 per baseplate
Software	VersaPro (v1.1 or higher), Logic Developer-PLC, Motion Programmer
LED Indicators	OK, CFG, STATUS, axis-specific LEDs
Operating Temperature	0°C to +60°C (32°F to +140°F)
Storage Temperature	-40°C to +85°C (-40°F to +185°F)
Relative Humidity	5% to 95% (non-condensing)
Weight	0.4 kg (0.88 lbs)
Dimensions	12.4 x 12.2 x 5.3 cm (4.9 x 4.8 x 2.1 in)
Mounting	Plugs into Series 90-30 PLC baseplate (5 or 10 slots)
Certifications	CE, UL, Class I Div 2

Manufacturer: General Electric (now under Emerson Automation)
Series: Series 90-30
Model/Part Number: IC693APU302P
Description: 2-Axis Positioning Module (APM) for motion and position control in industrial automation systems

The General Electric IC693APU302P is a dual-axis positioning module (APM) from the Series 90-30 Programmable Logic Controller (PLC) platform, originally manufactured by GE Fanuc and now managed by Emerson Automation. Designed for industrial automation, it controls two servo motor axes for precise motion and position control, integrating high-performance control with PLC logic. It is suitable for applications in manufacturing, CNC machinery, and material handling. The "-P" revision indicates a specific firmware or hardware update.

Specification	Details
Model	IC693APU302P
Series	Series 90-30
Type	Axis Positioning Module (APM)
Axes	2 independent motion axes
Operating Modes	Standard mode, Follower mode (electronic gearing)
Connectors	Two 9-pin D-shell connectors (one per axis), two 24-pin high-density connectors (servo connections)
Resolution	Configurable, based on servo drive feedback
Motion Programs	Up to 10 per module, stored in APM memory
Power Consumption	800 mA at +5 VDC from backplane
Isolation	1500 VAC (field-to-logic)
CPU Compatibility	Series 90-30 CPUs 311, 313, 323, or higher (modular CPU 331 or above for multiple modules)
Max Modules per System	8 (with CPU 331 or higher), max 3 per baseplate
Software	VersaPro (v1.1 or higher), Logic Developer-PLC, Motion Programmer
LED Indicators	OK, CFG, STATUS, axis-specific LEDs
Operating Temperature	0°C to +60°C (32°F to +140°F)
Storage Temperature	-40°C to +85°C (-40°F to +185°F)
Relative Humidity	5% to 95% (non-condensing)
Weight	0.4 kg (0.88 lbs)
Dimensions	12.4 x 12.2 x 5.3 cm (4.9 x 4.8 x 2.1 in)
Mounting	Plugs into Series 90-30 PLC baseplate (5 or 10 slots)
Certifications	CE, UL, Class I Div 2
