| Specification |
Details |
| Model |
IC200PWR001G |
| Series |
VersaMax |
| Type |
Power Supply Module |
| Input Voltage |
18–30 VDC, 24 VDC nominal |
| Input Current |
1.0 A max |
| Output Voltage |
5 VDC, 3.3 VDC |
| Output Current |
1.5 A total; up to 1.5 A at 5 VDC, up to 0.25 A at 3.3 VDC |
| Power Rating |
11 W |
| Holdup Time |
10 ms |
| Protection |
Short-circuit, overload, reverse polarity |
| Grounding |
DC- grounded to frame; floating configuration not supported |
| LED Indicators |
PWR (green, power status), OK (green, backplane status) |
| Backplane Power Consumption |
Provided by module, no additional backplane draw |
| Operating Temperature |
0°C to +60°C (32°F to +140°F) |
| Storage Temperature |
-40°C to +85°C (-40°F to +185°F) |
| Relative Humidity |
5% to 95% (non-condensing) |
| Weight |
0.42 kg (0.93 lbs) |
| Dimensions |
4.9 x 13.34 x 3.9 cm (1.93 x 5.25 x 1.54 in), excluding carrier |
| Mounting |
Snaps onto VersaMax CPU, NIU, or Power Supply Booster Carrier (IC200CHS003) |
| Certifications |
CE, UL, Class I Div 2, Temp Code T4A |
| Compatibility |
VersaMax PLCs, NIUs, and I/O modules |
