| Specification |
Details |
| Model |
IC200MDL330F |
| Series |
VersaMax |
| Type |
Discrete Output Module |
| Output Channels |
16 individually isolated |
| Output Voltage |
85–132 VAC, 120 VAC nominal, 47–63 Hz |
| Output Current |
0.5 A per point max; 10 mA min |
| Inrush Current |
5.0 A max for 20 ms (one cycle) |
| Output Voltage Drop |
2.0 V max |
| Output Leakage Current |
<2 mA at 132 VAC |
| Backplane Current Consumption |
140 mA max at 5 VDC |
| External Power Supply |
User-supplied 120 VAC for load switching |
| Isolation |
1500 VAC (channel-to-channel, channel-to-backplane), 250 VAC continuous |
| LED Indicators |
OK (backplane power), individual LEDs for each output |
| Operating Temperature |
0°C to +60°C (32°F to +140°F) |
| Storage Temperature |
-40°C to +85°C (-40°F to +185°F) |
| Relative Humidity |
5% to 95% (non-condensing) |
| Weight |
0.45 kg (1 lb) |
| Dimensions |
11 x 5 x 6.6 cm (4.3 x 2 x 2.6 in), excluding carrier |
| Mounting |
DIN rail or panel mount on VersaMax carrier (e.g., IC200CHS001, IC200CHS002) |
| Certifications |
CE, UL, Class I Div 2 |
| Compatibility |
VersaMax PLCs, Network Interface Units (NIUs) |
