| Input Channels |
4 differential thermocouple inputs |
| Thermocouple Types Supported |
J, K, T, E, R, S, B, N, C, D, L, U, W (per NIST ITS-90 / IEC 60584) |
| Temperature Range |
-270°C to +1820°C (varies by type) |
| Resolution |
16-bit (0.05°C typical, depending on range) |
| Accuracy |
±0.5°C typical (±1.0°C max) after calibration, excluding sensor; ±0.3°C with external CJC
|
| Cold Junction Compensation |
Dual internal sensors + external PT1000 option; ±0.2°C accuracy |
| Update Rate |
40 ms for all 4 channels (10 ms per channel sequential scan) |
| Input Impedance |
>20 MΩ |
| Open Circuit Detection |
Yes _ detects < 10 µA; upscale/downscale configurable per channel
|
| Burnout Detection |
Upscale/downscale per channel; drift monitoring
|
| Isolation |
1500 V RMS field-to-backplane; 250 V RMS channel-to-channel
|
| Common Mode Rejection |
>120 dB @ 50/60 Hz |
| Noise Rejection |
Configurable digital low-pass (0.1_100 Hz); adaptive 50/60 Hz notch
|
| Linearization |
Automatic per NIST Monograph 175 / IEC 60584; custom 32-point polynomial per channel
|
| Scaling |
User-defined units (°C, °F, K, mV, %FS); rate-of-change alarming
|
| Diagnostics |
Open circuit, burnout, over/underrange, CJC fault, sensor drift, self-test, watchdog, field power loss
|
| Safety Certification |
IEC 61508 SIL 2 capable (with certified application program) |
| Power Supply |
+5 V DC @ 140 mA, +3.3 V DC @ 100 mA (backplane) |
| Power Consumption |
0.8 W maximum |
| Communication Ports |
Dual Ethernet 10/100 Mbps (RJ45, switched) _ for firmware, config, OPC UA, process bus
|
| LED Indicators |
OK (green), Fault (red), 4x Active (green), CJC Status (blue), SV Stream (blue)
|
| Configuration |
Proficy Machine Edition (PME) 10.0+, web server, USB-C front port, OPC UA server) |
| Firmware |
Field-upgradable via Ethernet, USB-C, or PME
|
| Operating Temperature Range |
-40°C to +70°C (extended) |
| Storage Temperature Range |
-40°C to +85°C |
| Humidity |
5% to 95% non-condensing |
| Vibration |
IEC 60068-2-6 (10g, 10_500 Hz) |
| Shock |
IEC 60068-2-27 (50g, 11 ms) |
| Mounting |
Snaps onto VersaMax carrier base (IC200ACCxxx) |
| Dimensions |
4.33" x 2.60" x 1.77" (110 mm x 66 mm x 45 mm) |
| Weight |
0.46 lb (0.21 kg) |
| Enclosure Rating |
IP20 |
| Revision K Enhancements |
16-bit resolution, 40 ms update, dual Ethernet, external CJC, SIL 2, web config, IEC 61850-9-2 LE, enhanced EMC |
| Standards Compliance |
IEC 61131-2, IEC 61508 SIL 2, CE, UL, CSA, Class I Div 2, ATEX/IECEx Zone 2, IEC 61850-9-2, RoHS 3, IEC 61000-6-2/4
|
