GE G60C00HCHF8AH6PM8CPXXUXXWXX Transformer Protection and Control Relay

GE G60C00HCHF8AH6PM8CPXXUXXWXX Transformer Protection and Control Relay

  • Manufacturer: General Electric

  • Product No.: G60C00HCHF8AH6PM8CPXXUXXWXX

  • Condition:1000 in stock

  • Product Type: Transformer Protection and Control Relay

  • Product Origin: USA

  • Payment: T/T, Western Union

  • Weight: 1000g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

Product Details



Parameter Details
Manufacturer General Electric
Model/Part Number G60C00HCHF8AH6PM8CPXXUXXWXX
Description Transformer Protection and Control Relay

Product Overview



Parameter Details
Part Number G60C00HCHF8AH6PM8CPXXUXXWXX
Product Name G60 Transformer Protection System
Application Comprehensive protection, control, monitoring, and diagnostics for multi-winding power transformers in utility and industrial applications
Compatibility Integrates with GE Multilin Universal Relay (UR) series and substation automation systems; supports IEC 61850 Edition 2, DNP3, Modbus TCP, and Profibus DP
Function Provides advanced protection including differential, overcurrent, and thermal modeling; includes metering, event recording, and IEC 61850 GOOSE messaging

Functional Specifications



Parameter Details
Protection Functions Transformer differential (87T), restricted earth fault (87G), overcurrent (50/51), ground fault (50N/51N), thermal overload (49), over/under voltage (27/59), frequency (81O/U)
Measurement Capabilities Current, voltage, power, frequency, power factor; supports up to 6 three-phase current inputs and 3 three-phase voltage inputs; harmonic analysis up to 63rd order
Binary Inputs/Outputs 24 binary inputs, 16 output contacts (configurable)
Communication Interfaces 4x Ethernet ports (IEC 61850, DNP3, Modbus TCP), 2x serial ports (RS-485, IEC 60870-5-103), IRIG-B time synchronization
Power Supply 24-48 V DC or 125-250 V DC / 100-240 V AC options
Operating Temperature Range -40°C to +85°C
Dimensions 19" rack mount (4U height, 177 mm x 177 mm x 144 mm)
Weight 4.5 kg
Mounting 19" rack or panel mount
Protection Rating IP54 front panel
Standards Compliance IEC 60255, IEEE C37.91, IEC 61850 Edition 2, CE, UL, CSA
View full details

Product Description

Product Details



Parameter Details
Manufacturer General Electric
Model/Part Number G60C00HCHF8AH6PM8CPXXUXXWXX
Description Transformer Protection and Control Relay

Product Overview



Parameter Details
Part Number G60C00HCHF8AH6PM8CPXXUXXWXX
Product Name G60 Transformer Protection System
Application Comprehensive protection, control, monitoring, and diagnostics for multi-winding power transformers in utility and industrial applications
Compatibility Integrates with GE Multilin Universal Relay (UR) series and substation automation systems; supports IEC 61850 Edition 2, DNP3, Modbus TCP, and Profibus DP
Function Provides advanced protection including differential, overcurrent, and thermal modeling; includes metering, event recording, and IEC 61850 GOOSE messaging

Functional Specifications



Parameter Details
Protection Functions Transformer differential (87T), restricted earth fault (87G), overcurrent (50/51), ground fault (50N/51N), thermal overload (49), over/under voltage (27/59), frequency (81O/U)
Measurement Capabilities Current, voltage, power, frequency, power factor; supports up to 6 three-phase current inputs and 3 three-phase voltage inputs; harmonic analysis up to 63rd order
Binary Inputs/Outputs 24 binary inputs, 16 output contacts (configurable)
Communication Interfaces 4x Ethernet ports (IEC 61850, DNP3, Modbus TCP), 2x serial ports (RS-485, IEC 60870-5-103), IRIG-B time synchronization
Power Supply 24-48 V DC or 125-250 V DC / 100-240 V AC options
Operating Temperature Range -40°C to +85°C
Dimensions 19" rack mount (4U height, 177 mm x 177 mm x 144 mm)
Weight 4.5 kg
Mounting 19" rack or panel mount
Protection Rating IP54 front panel
Standards Compliance IEC 60255, IEEE C37.91, IEC 61850 Edition 2, CE, UL, CSA
