Product Description
General Electric G60-G01-HCH-F8F-H6P-M8H-P6P-U6P-WX Generator Protection Relay
Product Overview
- Description: The General Electric G60-G01-HCH-F8F-H6P-M8H-P6P-U6P-WX is a Multilin G60 generator protection relay designed for comprehensive protection, control, and monitoring of generators in power generation applications, including gas, steam, and hydro turbines. It provides advanced protection features such as differential protection, overcurrent, ground fault, and loss-of-excitation detection, along with high-speed metering, monitoring, and communication capabilities for integration into automation systems. The relay is part of GE’s Multilin UR series and differs from turbine control boards (DS200TCTGG1A) and excitation control systems (EX2100).
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | General Electric |
| Series | Multilin G60 (Universal Relay) |
| Model/Part Number | G60-G01-HCH-F8F-H6P-M8H-P6P-U6P-WX |
| Model Type | Generator Protection Relay |
| Function | Protects, controls, and monitors generators |
| Display | Graphical LCD with keypad |
| Inputs | 8 current inputs, 8 voltage inputs, 16 digital inputs |
| Outputs | 12 relay outputs, 4 analog outputs |
| Communication Interfaces | Modbus TCP/IP, IEC 61850, DNP3, Ethernet (dual ports), RS485 |
| Signal Conditioning | Internal signal processing for current, voltage, and digital inputs |
| Measurement Range | Phase current: 0.1–50 x CT rating Ground current: 0.02–5 x CT rating Voltage: 0.1–2 x VT rating |
| Accuracy | ±0.5% for current and voltage measurements |
| Redundancy | Non-redundant |
| Diagnostics | Self-test, event logging, waveform capture, cybersecurity logs |
| Compatibility | Integrates with SCADA systems, GE Multilin EnerVista software |
| Power Supply | 125–250 VDC or 100–240 VAC (50/60 Hz) |
| Power Consumption | 25 W max |
| Environmental Specifications | Operating Temperature: -40°C to +60°C Storage Temperature: -40°C to +85°C Relative Humidity: 5% to 95% non-condensing |
| Enclosure | IP40 (front), IP20 (rear) |
| Dimensions | 177 mm (H) x 483 mm (W) x 315 mm (D) |
| Weight | 7.5 kg |
| Mounting | 19-inch rack or panel mount |
| Certifications | CE, UL, cULus, IEC 61850 |
