GE F650BABF1GOHI Digital Bay Controller/Feeder Protection Relay

GE F650BABF1GOHI Digital Bay Controller/Feeder Protection Relay

  • Manufacturer: General Electric

  • Product No.: F650BABF1GOHI

  • Condition:1000 in stock

  • Product Type: Digital Bay Controller/Feeder Protection Relay

  • Product Origin: USA

  • Payment: T/T, Western Union

  • Weight: 1000g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

Product Details



Parameter Details
Manufacturer General Electric
Model/Part Number F650BABF1GOHI
Description Digital Bay Controller/Feeder Protection Relay

Product Overview



Parameter Details
Part Number F650BABF1GOHI
Product Name F650 Digital Bay Controller
Application Protection, control, monitoring, metering, and recording for feeders, busbars, transformers, and capacitor banks in power distribution and transmission systems
Compatibility Integrates with GE Multilin systems; supports substation automation via IEC 61850 (Edition 2)
Function High-speed protection and control for feeder management and bay control applications; supports digital I/O expansion

Functional Specifications



Parameter Details
Auxiliary Power Supply 110-250 V DC / 120-230 V AC (working range 88-300 V DC / 96-250 V AC)
Power Consumption 30 W DC / 30 VA AC, 50/60 Hz
Display Basic Display
Communication Interfaces Rear serial port 1: Redundant RS-485; Rear Ethernet port 2: 10/100 Base-TX; Protocols: Modbus RTU/TCP/IP, DNP 3.0 Level 2, IEC 60870-5-103, IEC 60870-5-104, IEC 61850 (Edition 2)
Digital I/O I/O board slot F: 16 binary inputs, 10 binary outputs (configurable)
Protection Functions Overcurrent (50/51), ground fault (50N/51N), directional overcurrent (67), voltage (27/59), thermal overload (49), breaker failure (50BF)
Measurement Capabilities Current, voltage, power, frequency; supports three-phase and residual measurements with event recording
Operating Temperature Range -40°C to +85°C
Dimensions 19" rack mount (4U height, 177 mm x 177 mm x 144 mm)
Weight 4.95 kg
Mounting 19" rack or panel mount
Protection Rating IP54 front panel
Standards Compliance IEC 60255, ANSI/IEEE C37.2, CE, UL, CSA
View full details

Product Description

Product Details



Parameter Details
Manufacturer General Electric
Model/Part Number F650BABF1GOHI
Description Digital Bay Controller/Feeder Protection Relay

Product Overview



Parameter Details
Part Number F650BABF1GOHI
Product Name F650 Digital Bay Controller
Application Protection, control, monitoring, metering, and recording for feeders, busbars, transformers, and capacitor banks in power distribution and transmission systems
Compatibility Integrates with GE Multilin systems; supports substation automation via IEC 61850 (Edition 2)
Function High-speed protection and control for feeder management and bay control applications; supports digital I/O expansion

Functional Specifications



Parameter Details
Auxiliary Power Supply 110-250 V DC / 120-230 V AC (working range 88-300 V DC / 96-250 V AC)
Power Consumption 30 W DC / 30 VA AC, 50/60 Hz
Display Basic Display
Communication Interfaces Rear serial port 1: Redundant RS-485; Rear Ethernet port 2: 10/100 Base-TX; Protocols: Modbus RTU/TCP/IP, DNP 3.0 Level 2, IEC 60870-5-103, IEC 60870-5-104, IEC 61850 (Edition 2)
Digital I/O I/O board slot F: 16 binary inputs, 10 binary outputs (configurable)
Protection Functions Overcurrent (50/51), ground fault (50N/51N), directional overcurrent (67), voltage (27/59), thermal overload (49), breaker failure (50BF)
Measurement Capabilities Current, voltage, power, frequency; supports three-phase and residual measurements with event recording
Operating Temperature Range -40°C to +85°C
Dimensions 19" rack mount (4U height, 177 mm x 177 mm x 144 mm)
Weight 4.95 kg
Mounting 19" rack or panel mount
Protection Rating IP54 front panel
Standards Compliance IEC 60255, ANSI/IEEE C37.2, CE, UL, CSA
