GE DS3800HAFA Analog Input/Output Board

GE DS3800HAFA Analog Input/Output Board

  • Manufacturer: General Electric

  • Product No.: DS3800HAFA

  • Condition:1000 in stock

  • Product Type: Analog Input/Output Board

  • Product Origin: USA

  • Payment: T/T, Western Union

  • Weight: 1000g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

Product Details



Parameter Details
Manufacturer General Electric
Model/Part Number DS3800HAFA
Description Analog Input/Output Board

Product Overview



Parameter Details
Part Number DS3800HAFA
Product Name DS3800HAFA Analog I/O Board
Application Analog signal processing in turbine control systems for power generation
Compatibility Designed for GE Speedtronic Mark IV turbine control systems; interfaces with I/O termination and control processors
Function Handles analog inputs/outputs for sensors and actuators; supports signal conditioning and isolation

Functional Specifications



Parameter Details
Type Analog I/O board with signal conditioning
Analog Inputs 16 x 4-20 mA, 8 x voltage (0-10 V)
Analog Outputs 8 x 4-20 mA, 4 x voltage (0-10 V)
Resolution 12-bit A/D and D/A conversion
Accuracy ±0.2% of full scale
Isolation 1500 V AC between field and logic side
Signal Conditioning Filtering, scaling, fault detection
Power Supply +5 V DC and ±15 V DC from system backplane
Power Consumption 15 W maximum
Operating Temperature Range -30°C to +70°C
Mounting Rack mount in control cabinet
Dimensions 10.5" x 8.5" x 1.5" (267 mm x 216 mm x 38 mm) approximate
Weight 2.5 lb (1.13 kg)
Protection Features Surge protection, EMI shielding
Standards Compliance IEC 61131-2, CE, UL, CSA
View full details

Product Description

Product Details



Parameter Details
Manufacturer General Electric
Model/Part Number DS3800HAFA
Description Analog Input/Output Board

Product Overview



Parameter Details
Part Number DS3800HAFA
Product Name DS3800HAFA Analog I/O Board
Application Analog signal processing in turbine control systems for power generation
Compatibility Designed for GE Speedtronic Mark IV turbine control systems; interfaces with I/O termination and control processors
Function Handles analog inputs/outputs for sensors and actuators; supports signal conditioning and isolation

Functional Specifications



Parameter Details
Type Analog I/O board with signal conditioning
Analog Inputs 16 x 4-20 mA, 8 x voltage (0-10 V)
Analog Outputs 8 x 4-20 mA, 4 x voltage (0-10 V)
Resolution 12-bit A/D and D/A conversion
Accuracy ±0.2% of full scale
Isolation 1500 V AC between field and logic side
Signal Conditioning Filtering, scaling, fault detection
Power Supply +5 V DC and ±15 V DC from system backplane
Power Consumption 15 W maximum
Operating Temperature Range -30°C to +70°C
Mounting Rack mount in control cabinet
Dimensions 10.5" x 8.5" x 1.5" (267 mm x 216 mm x 38 mm) approximate
Weight 2.5 lb (1.13 kg)
Protection Features Surge protection, EMI shielding
Standards Compliance IEC 61131-2, CE, UL, CSA
