General Electric DS200TCQCG1BKG Analog I/O Board
Product Overview
- Description: The General Electric DS200TCQCG1BKG is an analog input/output (I/O) board used in GE’s Mark V turbine control systems. It processes analog signals from sensors such as thermocouples
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | General Electric |
| Series | Mark V |
| Model/Part Number | DS200TCQCG1BKG |
| Model Type | Analog I/O Board |
| Function | Processes analog input/output signals for turbine control |
| Display | LED indicators (status) |
| Inputs | Multiple analog inputs (thermocouples, RTDs, 4–20 mA) |
| Outputs | Analog outputs (4–20 mA, voltage signals) |
| Communication Interfaces | Proprietary Mark V system interface |
| Signal Conditioning | Internal signal isolation and conditioning |
| Accuracy | ±0.5% for analog signal processing |
| Redundancy | Non-redundant |
| Diagnostics | LED status indicators, system-level fault reporting |
| Compatibility | GE Mark V turbine control systems |
| Power Supply | 125 VDC or 24 VDC (from Mark V system) |
| Power Consumption | 7 W max |
| Environmental Specifications | Operating Temperature: 0°C to +60°C Storage Temperature: -40°C to +85°C Relative Humidity: 5% to 95% non-condensing |
| Enclosure | IP20 (open, mounted in control cabinet) |
| Dimensions | 280 mm (H) x 200 mm (W) x 50 mm (D) |
| Weight | 1.3 kg |
| Mounting | Plugs into Mark V control cabinet slot |
| Certifications | CE, UL, RoHS |
