GE DS200TCQCG1A Analog I/O Board

GE DS200TCQCG1A Analog I/O Board

  • Manufacturer: General Electric

  • Product No.: DS200TCQCG1A

  • Condition:1000 in stock

  • Product Type: Analog I/O Board

  • Product Origin: USA

  • Payment: T/T, Western Union

  • Weight: 1000g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

Product Details



Parameter Details
Manufacturer General Electric
Model/Part Number DS200TCQCG1A
Description Analog I/O Board

Product Overview



Parameter Details
Part Number DS200TCQCG1A
Product Name DS200TCQCG1A Analog I/O Board
Application Analog input/output processing in turbine control systems for power generation
Compatibility Designed for GE Speedtronic Mark V turbine control systems; located in <R>, , and <T> cores; interfaces with TCCB terminal boards
Function Processes RTD, thermocouple, 4-20 mA, and voltage signals; supports scaling, linearization, and diagnostics

Functional Specifications



Parameter Details
Type Analog I/O board with signal conditioning
Analog Inputs 8 x 4-20 mA (12-bit resolution), 21 x RTD (Pt100/Ni120/Cu10), 3 x thermocouple (J/K/T/E)
Analog Outputs 2 x 4-20 mA (12-bit resolution)
Resolution 12-bit A/D and D/A conversion
Accuracy ±0.1% of full scale
Isolation 1500 V AC between field and logic side
Signal Conditioning Cold junction compensation (CJC) for thermocouples, RTD linearization, fault detection
Power Supply +5 V DC and ±15 V DC from system backplane
Power Consumption 12 W maximum
Operating Temperature Range -30°C to +70°C
Mounting Rack mount in Mark V control panel (<R>, , or <T> core)
Dimensions 10.5" x 8.5" x 1.5" (267 mm x 216 mm x 38 mm) approximate
Weight 2.5 lb (1.13 kg)
Connectors High-density ribbon cable to TCCB terminal board
Diagnostics LED status indicators, open/short detection, fault logging via IONet
Standards Compliance IEC 61131-2, CE, UL, CSA
View full details
