Product Description
General Information
- Manufacturer: General Electric
- Model/Part Number: C30
- Description: The General Electric C30 is a Controller System from the Multilin Universal Relay (UR) series, designed as a substation-hardened programmable logic controller (PLC) for substation automation and control. It provides fast and deterministic execution of programmable logic, expands I/O capabilities for protection devices, and can replace Sequence of Events (SOE) recorders. This device is tailored for bay control, offering advanced communication and customizable I/O options for industrial power system applications.
Technical Specifications
| Specification | Details |
|---|---|
| Type | Controller System (PLC) |
| Series | Multilin Universal Relay (UR) |
| I/O Capacity | Up to 96 digital inputs and 64 digital outputs |
| Communication | 3 independent Ethernet ports (IEEE 1588 support), RS485 |
| Supported Protocols | IEC 61850, DNP 3.0, Modbus TCP, IEC 60870-5-104, PRP |
| Control Power | 125–250 V DC, 100–240 V AC, 50/60 Hz |
| Operating Temperature | -40°C to +60°C |
| Weight | 5 kg (11 lbs) |
| Application | Substation automation, bay control, I/O expansion |
