Product Description
Product Overview
| Field | Details |
|---|---|
| Manufacturer | Schneider Electric (Foxboro) |
| Part Number | P0928DS |
| Product Type | Remote Graphics Unit (Quad) |
| Function | Connects H92 workstation to remote video, USB, and audio devices via fiber-optic cabling |
| System Compatibility | Foxboro Evo Process Automation System, Model H92 Workstation (Windows 7 Professional) |
| Associated Document | PSS 31H-4H92 |
| Kit Inclusion | Part of P0928DV Quad Remote Graphics Unit Kit (includes P0928DS, P0928DT PCIe card, P0972TP 15 m fiber cable) |
Functional Specifications
| Feature | Specification |
|---|---|
| Purpose | Extends H92 workstation interfaces (video, USB, audio) to remote locations |
| Interfaces | - Video: Four DisplayPort ports (supports up to four DisplayPort monitors) - USB: Five USB 2.0 ports (one supports BIOS-level keyboard; supports mouse, trackball, keyboard, USB speakers, up to four touchscreens via USB hub, floppy drive) - Audio: Microphone, audio input, audio output connections |
| Monitor Support | Up to 4 monitors (digital: DVI, DisplayPort; analog via DisplayPort to HD-15 adapter, sold separately) |
| Video Resolution | - Maximum Analog: 1920 x 1200 - Maximum Digital (DVI): 2048 x 1152 - Maximum DisplayPort: 2560 x 1600 |
| Distance | - OM1 (62.5/125 μm): Up to 70 m (230 ft) - OM2 (50/125 μm): Up to 150 m (492 ft) - OM3 (50/125 μm): Up to 380 m (1247 ft) - OM4 (50/125 μm): Up to 400 m (1312 ft) - OS1/OS2 (9/125 μm, single-mode): Up to 1000 m (3280 ft, user-supplied) |
| Cable Type | LC-LC optical, duplex; 15 m OM2 multi-mode 50/125 μm cable (P0972TP) included in kit; cables >50 m user-supplied |
| Cooling | Passive (fanless) |
| Operating Systems | Supports 64-bit: Windows 7, Windows Server 2008 R2, Windows Server 2008; 32-bit: Windows Vista, Windows XP, Windows Server 2003 |
| Estimated MTBF | 23.20 years at 40°C (excluding power supply) |
Physical Specifications
| Feature | Specification |
|---|---|
| Dimensions | - Height: 29 mm (1.15 in) - Width: 300 mm (11.8 in) - Depth: 147 mm (5.8 in) |
| Power Supply | - External: 90 to 264 V AC, 47/63 Hz, IEC 60320-C14 input connector - Output: 12 V DC, 60 W max, Mini-DIN 4 male (4-pin) with lock |
| Power Consumption | Max 60 W (with USB keyboard, mouse, two other USB devices, four DisplayPort monitors) |
| Power Protection | 5 A fuse for overcurrent protection |
| Laser Emissions | 850 nm laser, compliant to 21CFR Subpart J, Class 1 |
Environmental Specifications
| Parameter | Specification |
|---|---|
| Operating Temperature | 0 to 55°C (32 to 131°F), indoors in cabinet |
| Storage Temperature | -40 to 75°C (-40 to 167°F) |
| Operating Humidity | 20 to 80% (noncondensing), indoors |
| Storage Humidity | 5 to 95% (noncondensing), in packaged configuration |
| Operating Altitude | 0 to 3,580 m (0 to 11,745 ft), 650 to 1013 hPa |
| Storage Altitude | -50 to 12,000 m (-164 to 39,370 ft), 192 to 1020 hPa |
| Vibration | NEBS Level 3, Seismic Zone 4 (7.0 to 8.3 Richter scale) |
| Contamination | Class G1 (Mild) per ISA Standard S71.04 |
Regulatory Compliance
| Certification Type | Details |
|---|---|
| EMC | Class A: ACMA, CE, FCC, VCCI; complies with EU EMC Directive 2014/30/EU |
| Safety | Suitable for ordinary locations, meets safety standards for fire and shock hazards |
| Laser Emissions | 850 nm laser, compliant to 21CFR Subpart J, Class 1 |
Ordering Information
| Field | Details |
|---|---|
| Part Number | P0928DS (Remote Graphics Unit, Quad) |
| Kit Part Number | P0928DV (Quad Remote Graphics Unit Kit, includes P0928DS, P0928DT PCIe card, P0972TP 15 m fiber cable) |
| Related Components | - PCIe Card: P0928DT - Fiber Cable: P0972TP (15 m, included); OM1, OM2, OM3, OM4, OS1/OS2 for longer distances (user-supplied) - USB Hub: P0928EH, P0928EJ, P0923FS, P0923FT (for four touchscreens) |
| Related Documents | - PSS 31H-4H92: Model H92 Workstation Specifications - PSS 31H-4VDU: LCD Monitors - PSS 31H-4E1: Annunciator Keyboard/Panel - PSS 31H-1TIME: Time Synchronization Overview |
